Steel Pipe Reducer Manufacturer

Steel Pipe Reducer

A steel pipe reducer is a component used in the pipelines to reduce its size from large to small bore in accordance to the inner diameter. The length of the reduction here is equal to an average of the smaller and larger pipe diameters. Here, the reducer can be used as a diffuser or a nozzle.

Keywords

Concentric Reducer, Eccentric Reducer

Size

NPS:NPS from 3/4'' to 48'', DN from 20 to 1200,WT: 2-80mm, SCH 40/80/XXSS

Standard & Grade

310S

316/316L

316Ti

317L

321

API 5l GR.B/A671-CC-70/A515-50/A135-A/A170C

ASTM 234 WP 1/5/9/11/12/22/91

ASTM 403 304/304L

ASTM A105/A106/A53/A283-D

ASTM A234 WPB/WPC

Ends

Square Ends/Plain Ends (straight cut, saw cut, torch cut), Beveled/Threaded Ends

Delivery

Within 30 days and Depends on your order quantity

Payment

D/P

Usage

For conveying gas, water and oil either in the oil or natural gas industries

Uses of packaging in the steel industry

Protective function

- Prevent steel products from physical damage, such as collision, scratching and extrusion, during transport, storage and handling to avoid affecting the quality and appearance of the products.

- Insulate from external environmental factors, such as humid air, rain, dust, etc., to reduce the risk of rust and corrosion of steel and ensure the performance and service life of the products.

Wooden box packaging

- Use: Mainly used to protect some irregular shape, easy to damage or high requirements for packaging of steel products, such as precision parts and components.

- Specific description: the wooden box is made of thick wooden boards, and cushioning materials, such as foam, air cushion, etc., may be added inside to reduce the impact of vibration and collision on the product.

Anti-rust paper packaging

- Purpose: To prevent rust and corrosion of steel products, especially suitable for storage or transportation in a humid environment.

- Specific description: anti-rust paper usually contains rust inhibitors, can be in contact with the metal surface to form a protective film, blocking the erosion of moisture and oxygen.

Plastic film packaging

- Purpose: To provide basic protection against dust and moisture, commonly used for small steel products.

- Specific description: plastic film has a certain degree of flexibility and sealing, can be tightly wrapped in the product surface, effectively isolate the external environment.

Pallet packaging

- Purpose: To facilitate the stacking and handling of steel products, and improve logistics efficiency.

- Specific description: The pallet is usually made of wood or plastic, the steel products are placed on the pallet, and then the forklift and other tools can be used for handling and loading and unloading.

Factory container packing

- Purpose: It is used for mass transportation of iron and steel products, to protect the products and improve the utilization rate of transportation space.

- Specific description: Containers have a strong structure and good sealing, and can adapt to long-distance transportation and the conversion of multiple modes of transportation.

Anti-rust oil coating packaging

- Purpose: To form a layer of antirust oil film on the surface of steel and enhance the antirust ability.

- Specific description: evenly cover the steel surface with anti-rust oil by brushing or soaking to form a durable protective layer.

Metal Corner Protection Packaging

- Purpose: To protect the corners and edges of steel products from damage during handling and transportation.

- Specific description: Metal corner guards are usually installed on the corners of products, using welding, bolting and other methods to increase the strength and impact resistance of the corners.

Baling Steel's packaging will surely convey to you our dedication to quality. We understand the importance of packaging to the quality of steel products and transportation safety, so we strive for excellence in the selection of packaging materials, so that you do not have to worry about the loss of transportation, and fully feel our professionalism and dedication!

Click to enlarge

Back to products

Category: Pipe Fittings and Flange

Description

Steel reducers are components used in piping systems to change the diameter of the pipe. They are designed to smoothly transition from one pipe size to another, reducing or increasing the flow rate as needed.

Concentric reducers

A concentric reducer has the centerlines of the inlet and outlet in the same axis. Concentric reducers are typically used when the fluid flow needs to remain centered and there is no need to accommodate any obstacles or clearances.

Eccentric reducers

An eccentric reducer has the centerlines offset.Eccentric reducers are used when there is a need to avoid interference with other components or to accommodate changes in elevation.

Additional information

Keywords	Concentric Reducer, Eccentric Reducer
Size	NPS:NPS from 3/4'' to 48'', DN from 20 to 1200,WT: 2-80mm, SCH 40/80/XXSS
Standard & Grade	310S , 316/316L , 316Ti , 317L , 321 , API 5l GR.B/A671-CC-70/A515-50/A135-A/A170C , ASTM 234 WP 1/5/9/11/12/22/91 , ASTM 403 304/304L , ASTM A105/A106/A53/A283-D , ASTM A234 WPB/WPC
Ends	Square Ends/Plain Ends (straight cut, saw cut, torch cut), Beveled/Threaded Ends
Delivery	Within 30 days and Depends on your order quantity
Payment	D/P , LC , OA , TT
Usage	For conveying gas, water and oil either in the oil or natural gas industries
