Seamless Steel Elbow
Steel pipe elbow is a key parts in a piping system for to change the fluid flow direction. It is used to connect two pipes with same or different nominal diameters, and to make the pipe turn to a certain direction of 45 degree or 90 degree.
Description
A steel elbow is a crucial component in piping systems that allows for the alteration of the flow direction of fluids or gases. It is crafted from steel, a strong and durable material capable of withstanding significant pressure, temperature variations, and corrosive substances.
Steel elbows are typically made from high-quality steel alloys to ensure durability and resistance to pressure, corrosion, and temperature variations. They come in various sizes and angles, such as 90 degrees, 45 degrees, or custom angles depending on the specific requirements of the piping layout.
The surface of the steel elbow may be smooth or have certain coatings or treatments to enhance its performance and lifespan. Common types of steel elbows include seamless elbows and welded elbows, each with its own manufacturing process and characteristics.
The choice of the appropriate steel elbow depends on factors such as the type of fluid or gas being transported, the operating pressure and temperature, the pipe size, and the overall piping design
Seamless Steel Elbow
Manufactured without any welded seams, providing enhanced strength and integrity
Welded Steel Elbow
Joined together through welding processes and suitable for various applications
Long Radius Elbow
It provides a smoother flow transition and is often used in applications where minimizing pressure drop is crucial, such as in large-scale piping systems for fluids with high flow rates
Short Radius Elbow
It takes up less space and is suitable for installations where space is limited. However, it causes a relatively higher pressure drop compared to the long radius elbow
90-Degree Steel Elbow
Changes the flow direction by approximately 90 degrees,Commonly used to make a right-angle turn in the piping system.
45-Degree Steel Elbow
Changes the direction of the flow at a 45-degree angle and is used when a less sharp turn is needed
Additional information
| Keywords |
45 Degree,90 Degree,180 Degree Elbow,Long Radius,Short Radius Elbow |
|---|---|
| Size |
NPS:1/2''~24''(Seamless),24''~72''(Welded);DN: 15~1200, WT: 2~80mm, SCH 5~XXS or according to client's requirements. |
| Standard & Grade |
ASTM A105,ASTM A182, ASTM A234 WPB, ASTM A403 304/304L/310/310S/316/316L/317L/321,ASTM A234 WP1/5/9/11/12/22/91 |
| Ends |
Square Ends/Plain Ends (straight cut, saw cut, torch cut), Beveled/Threaded Ends |
| Delivery |
Within 30 days and Depends on your order quantity |
| Payment |
D/P ,LC ,OA ,TT |
| Usage |
For conveying gas, water and oil either in the oil or natural gas industries |
Reviews (0)
Shipping & Delivery
Uses of packaging in the steel industry
Protective function
- Prevent steel products from physical damage, such as collision, scratching and extrusion, during transport, storage and handling to avoid affecting the quality and appearance of the products.
- Insulate from external environmental factors, such as humid air, rain, dust, etc., to reduce the risk of rust and corrosion of steel and ensure the performance and service life of the products.
Wooden box packaging
- Use: Mainly used to protect some irregular shape, easy to damage or high requirements for packaging of steel products, such as precision parts and components.
- Specific description: the wooden box is made of thick wooden boards, and cushioning materials, such as foam, air cushion, etc., may be added inside to reduce the impact of vibration and collision on the product.
Anti-rust paper packaging
- Purpose: To prevent rust and corrosion of steel products, especially suitable for storage or transportation in a humid environment.
- Specific description: anti-rust paper usually contains rust inhibitors, can be in contact with the metal surface to form a protective film, blocking the erosion of moisture and oxygen.
Plastic film packaging
- Purpose: To provide basic protection against dust and moisture, commonly used for small steel products.
- Specific description: plastic film has a certain degree of flexibility and sealing, can be tightly wrapped in the product surface, effectively isolate the external environment.
Pallet packaging
- Purpose: To facilitate the stacking and handling of steel products, and improve logistics efficiency.
- Specific description: The pallet is usually made of wood or plastic, the steel products are placed on the pallet, and then the forklift and other tools can be used for handling and loading and unloading.
Factory container packing
- Purpose: It is used for mass transportation of iron and steel products, to protect the products and improve the utilization rate of transportation space.
- Specific description: Containers have a strong structure and good sealing, and can adapt to long-distance transportation and the conversion of multiple modes of transportation.
Anti-rust oil coating packaging
- Purpose: To form a layer of antirust oil film on the surface of steel and enhance the antirust ability.
- Specific description: evenly cover the steel surface with anti-rust oil by brushing or soaking to form a durable protective layer.
Metal Corner Protection Packaging
- Purpose: To protect the corners and edges of steel products from damage during handling and transportation.
- Specific description: Metal corner guards are usually installed on the corners of products, using welding, bolting and other methods to increase the strength and impact resistance of the corners.
Baling Steel's packaging will surely convey to you our dedication to quality. We understand the importance of packaging to the quality of steel products and transportation safety, so we strive for excellence in the selection of packaging materials, so that you do not have to worry about the loss of transportation, and fully feel our professionalism and dedication!
